1U, 4-slot, active chassis, manageable

Passive Single-Fiber Rapid Expansion Solution, utilizing one fiber to carry multiple business data streams, without the need for power supply, achieved purely through optical components, with low failure rate and quick deployment, suitable for environments with relatively scarce fiber core resources over medium and short distances.

Availability:



Inquire

Semi-active Single-Fiber Rapid Expansion Solution, utilizing one fiber to carry multiple business data streams, with active support and management at the central office, passive at the remote end, achieved purely through optical components, with low failure rate and quick deployment, supporting protection, suitable for environments with relatively scarce fiber core resources over medium and short distances that require protection.

EDGESMAT CWDM System Solution supports 6 waves and 12 waves. The central office supports standard 19-inch 1U, 2U, 3U, and 5U rack frames, with active power supply 1+1 protection, main control 1+1 protection at the central office, supporting power supply temperature, current, voltage monitoring, as well as fan speed control and monitoring. The remote outdoor rack frame supports installation methods such as pole mounting and wall mounting.

1. Passive Single-Fiber Rapid Expansion Solution

Passive solution, high reliability, maintenance-free: Implemented with pure optical devices, high reliability, low failure rate, no network management maintenance required.
Easy to install: Small size (130mm*100mm*25mm), light weight, compact and portable, can be flexibly carried and installed.
Strong environmental adaptability: waterproof, dustproof, resistant to high and low temperatures, can be applied in various complex environments.
Business transparency: All reused business processes are transparently transmitted, regardless of speed or business type.
Rich variety of solutions: Supports 1:4/1:6/1:8/1:12/1:16/1:18, supports point-to-point and chain networking, flexible selection according to needs, refined investment.
High compatibility: Suitable for various mainstream CPRI interfaces of 1G/2G/5G/6G/10G/25G from different vendors, as well as Ethernet and SDH interfaces.
Distance Application: Supports engineering transmission distances of 10Km, 20Km, and 40Km, 100% meeting the transmission requirements for medium and short distances.

2. Semi-active Single-Fiber Rapid Expansion Solution

Manageable: The central end has an active source and can be managed directly through SNMP, while there is currently no management solution for the remote end.
Line protection: Supports line protection switching, switching time <50ms.
Breakpoint Detection: Supports testing of optical fiber breakpoint positions with a precision of <5m, facilitating the restoration of fiber optic links (optional).
Easy to install: The remote unit is small (130mm*100mm*25mm), lightweight, compact and portable, allowing for flexible carrying and installation.
High reliability: The remote device is realized with pure optical components, maintenance-free, water-resistant, dustproof, resistant to high and low temperatures, and has strong environmental adaptability.
Business transparency: All reused business processes are transparently transmitted, regardless of speed or business type.
Rich variety of solutions: Supports 1:6/1:12//1:18 (customizable), supports point-to-point and chain networking, flexible selection according to needs, refined investment.
High compatibility: Suitable for various mainstream CPRI interfaces of 1G/2G/5G/6G/10G/25G from different vendors, as well as Ethernet and SDH interfaces.
Distance Application: Supports engineering transmission distances of 10Km, 20Km, and 40Km, 100% meeting the transmission requirements for medium and short distances.
